3.8m Discharge Height Concrete Mixing Plant 145KW Power With 4 Aggregate Bin

Product Categories

Sinoway Industrial (Shanghai) Co., Ltd.

Contact Now

Name: 38m Discharge Height Concrete Mixing Plant 145KW Power With 4 Aggregate Bin
Brand: SINOWAY
Price: 1 USD

Brand Name : SINOWAY

Model Number : SWCMP900

Certification : ISO9001

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : D/A, L/C, D/A, D/P, T/T, Western Union

Supply Ability : 5 set per month

Delivery Time : 30 days

Packaging Details : Nude

Capacity Per Hour : 65 m³/h

Capacity of the aggregate bin : 4×15m³

Discharge height : 3.8m

Total power : 145KW

Working voltage and frequency : 380 V/50 Hz

Control voltage : DC24 V

Contact Now

Mobile Asphalt Plant 65 m³/h Prouduction Capacity Mobile Batching Plant With 4 Aggregate Bin

Main Technical specifications
Productivity in actual	65 m³/h
Model of the mixer	SWM1500
Power of the mixing motor	2×30 kW
Cycle time	50 s
Volume of the mixer	1.5 m³
Capacity of the powder silo	4×100 ton
Capacity of the aggregate bin	15 m³
Number of aggregate bin	4
Conveying capacity of the Inclined belt conveyor	250 ton/hour
Discharge height	3.8 m
Total power	145 kW
Weighing range and accuracy of the stone	2x3000±1% kg
Weighing range and accuracy of the sand	2×3000±1% kg
Weighing range and accuracy of the cement	1000±1% kg
Weighing range and accuracy of fly ash	400±1% kg
Weighing range and accuracy of the water	300±1% kg
Weighing range and accuracy of the admixture	50±1% kg
Working voltage and frequency	380 V/50 Hz
Control voltage	DC24 V

3.8m Discharge Height Concrete Mixing Plant 145KW Power With 4 Aggregate Bin
